Rio Hondo El Monte Concrete saws a failed bay out on its own joints, takes out the loose fill or the root beneath it, and repours 4 inches to the city detail with the encroachment permit in our name.
5.0 Stars How our customers score us · Facebook, Google and the BBB
Before you pay for it yourself
Look at the city map before you spend anything. The state duty is real, Streets and Highways Code section 5610 makes the fronting owner responsible for the footway, and El Monte does not stop there. The city has surveyed every panel into a GIS sidewalk inventory, built three reconstruction phases off the back of it, and publishes the repair map in English, Spanish and Vietnamese. Ten minutes with that map tells you whether your frontage is already programmed.
Ismael Duarte has poured here since 2015, after 21 years on other outfits' crews, and he sets the string on anything past the property line himself. The detail changes street by street on this grid: some blocks carry the walk hard against the curb, others hold it back behind a parkway strip wide enough for a tree. Which one your address has decides where the forms sit and whether roots are in the argument at all.
Right-of-way work runs on a CSLB C-8 license and an encroachment permit from Public Works, not from the building counter over in City Hall West. El Monte wants three things attached to that application: a contractor's license, a City of El Monte business license, and proof of insurance naming the city as an additional insured. We hold all three, so it goes in the day you sign. liability insurance on every job covers the saw and the truck while they are on your frontage.
When patching stops working
Quarter of an inch is where a raised edge stops being cosmetic, and it is the measurement every argument about a walk turns on. A lip does not settle back down of its own accord, either. Whatever pushed the bay up is still under there, and it will have grown by next spring.
Concrete that shifts when you put weight on one end has lost its bearing. On these blocks that is nearly always old trench backfill washing out, because clean river sand travels wherever water is let into it. A bay left bridging a void will break across the middle rather than settle.
Short cracks radiating out of one corner point downward at a root, not at shrinkage. Roots hunting the wet ground beside a parkway sprinkler stay shallow and spread sideways beneath the concrete, and a bay one has crossed comes apart into pieces that move independently.
Rounded river stone standing proud of the top of a bay means the mortar skin has worn off and the panel is failing downward from the surface. Walk laid on this grid in the 1960s was often finished thin, and once the aggregate is exposed there is nothing left to grind flat.
On every bay
None of the following is priced as an extra. A bay in the right-of-way answers to a city standard drawing, an inspector and whatever is growing in the parkway, so the specification is fixed before anybody counts anything.
The failed bay is sawn out along its existing joints, so it lifts in one piece and the runs either side of it stay put.
Loose backfill under the bay is dug out rather than packed down again, because on this ground that fill is what dropped the panel.
Any root over an inch across is severed square beyond where the new form line sits, then the face is sealed and the tree left standing.
Ribbed barrier stood on edge between trunk and concrete, deep enough that the next root goes down and beneath rather than along.
Class 2 base rolled tight over the full width of the bay, so the concrete beds on made ground rather than washed sand.
A full 4 inches of 3,500 psi mix, with the broom drawn across the walk instead of along the line people travel on it.
Forms are leveled off the curb face and the property line to the city standard drawing, and the finished fall is read twice.
We file the encroachment permit, meet the Public Works inspector at your address, and seal the cure before the crew packs up.
Your options
What a household here chooses between once the walk has moved, set against how long each answer holds, when it is the right one, whether the city has to sign it, and how long your frontage is out of use. One of the four puts the level back.
| Option | Holds for | Best when | Permit | Walk closed |
|---|---|---|---|---|
| Full bay repour | 30 to 40 years | A root has lifted it or the surface has gone | Encroachment permit and an inspection | 1 or 2 days, then a week of curing |
| Waiting on a city phase | 30 to 40 years | Your frontage is already on the repair map | None, the city runs its own contract | Whenever the phase reaches your block |
| Grinding the step out | 1 to 2 years | Only to clear a hazard before a sale | Not needed for a shave under an inch | About an hour, and you can walk on it |
| Lifting the dropped bay | 5 to 10 years | A bay that has settled with no root under it | None, since nothing is removed | Half a day, and it is usable that evening |
Neither grinding nor lifting touches whatever moved the bay, so on a treed parkway a shaved panel is normally stepped again inside a couple of years.
Local knowledge
The ground under this city is not what breaks its sidewalks. A hundred years of opening that ground up is.
The valley floor here is San Gabriel River wash, sand and rounded gravel, free draining, and holding no cut face at all. Water, gas and sewer have been trenched under these blocks since the townsite was laid out in 1912, and each backfill has gone down at its own rate since. That settlement, not the native ground, is the void a rocking bay bridges. So the walk line is probed before any form goes in and the soft stuff lifted out. Your own block appears on the USDA Web Soil Survey.
The second local particular is the street rather than the walk. Any street El Monte has reconstructed or slurry sealed is shut to cutting for five years, on a published list and map, so work that has to break the gutter line either waits out that clock or gets routed around it. Summer is no obstacle at this end of the county: August afternoons average 87.6 degrees here, mild against the towns inland, and an early start with the surface kept damp is the whole of it.
Our process
One crew from the first measurement through to the inspector's signature, and one figure written at your curb. The encroachment permit is filed by us, in our name, well before a saw blade goes near the walk.
Ismael Duarte lays a straightedge across the lip, counts the bays either side of it, and takes a good long look at the parkway.
Your frontage is checked against the city repair map first. If it is not queued, the encroachment permit goes in through the CSS portal.
Bays are cut on their own joints and lifted whole, the soft fill beneath them is removed, and any root is pruned and shut out behind barrier.
Base rolled, forms shot off the curb, cross fall held under 2 percent, then the concrete, the broom finish and the joints inside a day.
The cure goes on the same afternoon and the parkway soil is reset. Once the inspector passes the run, your guarantee paperwork follows.
What moves the estimate
Start with the bay count, since a bay is roughly 5 feet square and every other line attaches to it. What shifts the figure after that is the parkway, the street's own recent record, and how the public gets past while the forms are standing.
Two bays and the crew is away by lunch. A full property line means a longer permit, a marked route past the work and two days of forming.
A mature parkway tree turns one bay into root work, a barrier and a deeper dig, and it decides where the new form line is allowed to sit.
A street the city resurfaced within five years cannot be cut, so anything needing the pavement opened either waits or is routed around it.
Frontages here run from a narrow walk tight to the curb up to a full parkway detail, and the wider drawing is more concrete and more forming.
Nothing here is worked out off an aerial photo. The visit is free, the number is written at your frontage, and looking your block up on the city map is part of it. (626) 774-7973 or send us a message.
Ask for a visit; you get a call back within 1 business day. What you are given is a time at your own curb, not a figure quoted down the phone. We count bays, look your block up on the city map together, and leave the estimate on paper.
Reviews
Three frontages this crew rebuilt, reviewed on Google, Facebook and the BBB. A root job, a bay that had dropped and a corner at an approach, three different problems, not one told over.
“Two bays outside ours had a step in them you could catch a foot on. They pulled up the city map first and our block was not on it, so we went ahead. Bays out on the joints, roots cut back behind a barrier, and the inspector passed it the same week. Reads flat from the corner now.”
“One end of our walk had dropped where the water line went in decades ago, and it held a puddle every time the sprinklers ran. They dug the old fill right out instead of packing it back down, rolled base in and poured three new bays. Dry along that joint all summer.”
“Ours crosses the driveway approach and the corner of it had broken into three pieces. They took out the permit themselves, matched the ramp back into the apron, and the frontage was walkable again inside two days. My mother uses a walker on it and nothing catches.”
FAQ
Which department takes the application, what happens to the tree, who ends up paying for it, and the dimensions a bay in the right-of-way must meet, answered for the walk at your own address rather than for concrete generally.
Check the city map before you assume the bill is yours. The state duty is genuine: Streets and Highways Code section 5610 makes the fronting owner responsible for the footway. El Monte adds a program. Every panel has been inventoried into a GIS database, three reconstruction phases are built, and the sidewalk repair map is published in three languages. If your block is programmed, waiting costs nothing.
An encroachment permit, and it comes from Public Works rather than from Building & Safety over at City Hall West. The application wants a contractor's license, a City of El Monte business license and proof of insurance with the city named as an additional insured, and it is filed through the CSS portal. We do all of that in our name. A path inside your own boundary needs none of it.
It holds for a year or two and it treats nothing. A grinder takes off about an inch, enough to clear a hazard before a sale or an inspection, but the root that raised the bay carries on growing through every wet winter and the step comes back. And where the panel has cracked through as well, grinding just leaves you a flat bay in three pieces.
It stays, almost always. A bay is lifted by the flat feeder roots directly beneath it, and those get cut square beyond the new form line, sealed, and then kept out by a 24-inch barrier standing on edge between the trunk and the concrete. Nothing structural holding the tree upright is disturbed. Where it is a city tree, pruning or removal is the city's decision to take.
Width follows whichever city sidewalk detail your street was built to, which is why a walk against the curb on one block is set back behind a parkway on the next. Cross fall matters more than width. It stays under 2 percent, which is the figure that keeps a surface usable on wheels, and a level is run over the finished bay before a single form is stripped.
Two or three bays is a single working day; a whole property line runs to two. The permit is the slower part, and that application is lodged as soon as you sign. Once the concrete is down, stay off it completely for 24 hours, then keep bicycles, bins and anything on wheels away for 7 days while strength builds. The marked route past the work stays up throughout.
Because the native ground barely moves and the fill in it does. There is no swelling clay under this part of the valley, it is river sand and rounded gravel, which drains and compacts well and stays where it is put. What has never settled properly is the backfill over a century of water, gas and sewer trenches, and a bay sitting over one of those has somewhere to go.
Yes. The bay comes to you under a written workmanship guarantee against defects in how it was built, reaching under the surface as much as the surface: the dig, the compaction, the depth and the joint layout. The wording is on the estimate you sign, not on a leaflet. Outside it sit a bay lifted later by a tree planted after we have gone, and breakage where vehicles cross the walk with no approach under them.
Service area
The eight nearest towns on our round, with the straight-line distance from Peck Road beside each one. Every city out here issues its own right-of-way permit, and getting that filed is our end of the job rather than yours.
Four more jobs worth measuring while someone is at the address anyway, with the crew, the saw and the concrete truck already committed to your street.
The drive repoured to meet your new bays at one clean grade.
One corner taken out square, so a single bay comes up rather than four.
Front steps up onto an older porch, formed while the walk is out.
A low wall holding the front garden back off the walk, footed and drained.
Send us the address and someone calls you within 1 business day. They stand at the frontage, count what has to come out and leave the figure with you on paper. The permit is ours to chase from that point on, and the visit costs nothing.
